40×1 Berg Strip Straight Female Connector

Feature:

• 1.27mm Pitch
• 1×40 Pins
• Through-Hole Mounting

Specifications:

• Connector: Header Strip
• Gender: Female
• Pin Spacing: 1.27 mm
• No of Rows: 1
• Contact Material: Phosphor Bronze
• Contact Resistance: 20mΩ
• Insulation Material: PBT UL 94V-0
• Insulation Resistance: ≥1000MΩ
• Mounting Type: Through Hole
• Length: 51 mm
• Width: 1.56 mm
• Height: 7 mm
• Weight: 3 gm

Package Includes:

• 1 x 40×1 Berg Strip Straight Female Connector – 1.27mm Pitch

Note: Product Images are shown for illustrative purposes only and may differ from the actual product.
